MA3600
MA3600
Technical specifications
| Model | MA3600 |
| 20Hz-20KHz, 01% THD + N | |
| 8ΩStereo Power | 1200Wx2 |
| 4ΩStereo Power | 1800Wx2 |
| 8ΩBridge Mono Power | 3600W |
| Frequency Response | 20Hz-20Khz,-3dB@1000Khz |
| Protection | Short-circuit, thermal,ultrasonic, Infrasonic, DC fault, over current, |
| THD +N | 0.05% |
| Damping Factor | 600:1 |
| S/N Ration | >95dB |
| Segreation ratio | >70dB |
| Input Sensitivity(Rated Power at 8Ω) | 0.775v,1.0V,1.4V |
| Input Impedance (Balance/Unbalance) | 20KΩ/Balance, 10KΩUnbalance |
| Input Connectors (per channel) | 3-pin XLR |
| Output Connectors(per channel) | Neutrik@NL4 Spealkon |
| Power Supply(Factory Configured) | 220V-240V,50-60Hz |
| Cooling | Variable speed fans |
| LED Indicators | Protect, Clips, Signal, Power |
| Construction | Steel chassis |
| Packing Dimensions | 660x590x230mm |
| Height | 3U |
| Gross Weight | 42kgs |
